TSP40 FM TUNER
Opis
Opis na stronie producenta: https://audac.eu/Products/d/tsp40---fm-tuner
SYSTEM SPECIFICATIONS | ||||
---|---|---|---|---|
Control | Front panel | |||
RS-232 | ||||
Sensitivity (1W/1m) | -100 dBm | |||
Signal / Noise | 42 dB | |||
THD+N (@ 1 kHz) | < 0.1% | |||
Crosstalk (@ 1 kHz) | 42 dB | |||
Inputs | F-type antenna connection (75 Ω) | |||
Operating temperature | 0° ~ 40° @ 95% Humidity | |||
FM | Tuning Range (-10 dB) | 64 ~ 108 MHz | ||
Frequency | Response (± 3 dB) | 30 Hz - 15 kHz | ||
Outputs | Type | Balanced stereo line outputs (3-pin Euro Terminal Block (Pitch - 3.81 mm)) | ||
Level | +8 dB ~ -55 dB | |||
Display | Type | 2.8” Graphical LCD | ||
Power | Source | 110 ~ 240 V AC / 50 ~ 60 Hz | ||
Consumption | 0.5 W | |||
Supply | Switching mode |
PRODUCT FEATURES | ||||
---|---|---|---|---|
Dimensions | 482 x 44 x 330 mm (W x H x D) | |||
Weight | 3.150 kg | |||
Mounting | 19” | |||
Unit height | 1 HE | |||
Construction | Steel | |||
Colours | Black | |||
Accessories | Included | Antenna cable | ||
Optional | ASK40S 4-way antenna splitter kit | |||
2.4 GHz remote control |
