TSP40 FM TUNER
Dostępność:
dostępny na zamówienie
Ocena:
0
0
Producent:
Kod produktu:
TSP40
Opis
Opis na stronie producenta: https://audac.eu/Products/d/tsp40---fm-tuner
| SYSTEM SPECIFICATIONS | ||||
|---|---|---|---|---|
| Control | Front panel | |||
| RS-232 | ||||
| Sensitivity (1W/1m) | -100 dBm | |||
| Signal / Noise | 42 dB | |||
| THD+N (@ 1 kHz) | < 0.1% | |||
| Crosstalk (@ 1 kHz) | 42 dB | |||
| Inputs | F-type antenna connection (75 Ω) | |||
| Operating temperature | 0° ~ 40° @ 95% Humidity | |||
| FM | Tuning Range (-10 dB) | 64 ~ 108 MHz | ||
| Frequency | Response (± 3 dB) | 30 Hz - 15 kHz | ||
| Outputs | Type | Balanced stereo line outputs (3-pin Euro Terminal Block (Pitch - 3.81 mm)) | ||
| Level | +8 dB ~ -55 dB | |||
| Display | Type | 2.8” Graphical LCD | ||
| Power | Source | 110 ~ 240 V AC / 50 ~ 60 Hz | ||
| Consumption | 0.5 W | |||
| Supply | Switching mode | |||
| PRODUCT FEATURES | ||||
|---|---|---|---|---|
| Dimensions | 482 x 44 x 330 mm (W x H x D) | |||
| Weight | 3.150 kg | |||
| Mounting | 19” | |||
| Unit height | 1 HE | |||
| Construction | Steel | |||
| Colours | Black | |||
| Accessories | Included | Antenna cable | ||
| Optional | ASK40S 4-way antenna splitter kit | |||
| 2.4 GHz remote control | ||||
