SMA500 WAVEDYNAMICS™ DUAL-CHANNEL POWER AMPLIFIER 2 X 500W
Dostępność:
dostępny na zamówienie
Ocena:
0
0
Producent:
Kod produktu:
SMA500
Opis
Opis na stronie producenta: https://audac.eu/Products/d/sma500---wavedynamics-dual-channel-power-amplifier-2-x-500w
| SYSTEM SPECIFICATIONS | |||||
|---|---|---|---|---|---|
| Signal / Noise | > 95 dB | ||||
| THD+N (@ 1 kHz) | < 0.05% (1/2 Rated Power) | ||||
| Crosstalk (@ 1 kHz) | > 70 dB | ||||
| Technology | Class-D | ||||
| Common mode rejection ratio | 70 dB | ||||
| Damping factor | > 200 | ||||
| Cooling | Temperature controlled FAN | ||||
| Operating temperature | 0° ~ 40° @ 95% Humidity | ||||
| Frequency | Response (± 3 dB) | 20 Hz - 20 kHz | |||
| Inputs | Sensitivity (1W/1m) | -19.5 dB ~ 27 dB | |||
| Impedance | 10 kΩ balanced | ||||
| Connector | XLR & 3-pin Euro Terminal Block (3.81 mm) | ||||
| Outputs | Connector | Speakon compatible & 2-pin Euro Terminal Block (5.08 mm) | |||
| Protection | Amplifier | DC Short circuit | |||
| Over heating | |||||
| Over load | |||||
| Signal limiting | |||||
| Loudspeaker | Power limiter | ||||
| Access | User & Administrator level (Through password and USB-key protection) | ||||
| Power | Supply | Switching mode | |||
| AC Input: 100-120V/220-240V~ 50/60Hz | |||||
| Note: Standard voltage and frequency of electricity varies from country to country. Please contact your local distributor to ensure suitable product variant voltage and frequency compatibility. | |||||
| RMS Power | @ 4 Ω Stereo | 2 x 500 W | |||
| @ 8 Ω Bridge | 1000 W | ||||
| @ 8 Ω Stereo | 2 x 300 W | ||||
| PRODUCT FEATURES | ||||
|---|---|---|---|---|
| Dimensions | 482 x 88 x 420 mm (W x H x D) | |||
| Weight | 7.450 kg | |||
| Mounting | 19” | |||
| Unit height | 2 HE | |||
| Construction | Steel | |||
| Colours | Black | |||
